Dimensions and technical specifications
| Model | E4000I |
|---|---|
| Power supply voltage | 220-240V~ 50/60 Hz to board switching power supply unit |
| Motor max power | 150 W |
| Accessories power supply | 1A |
| Max. accessories load | 24V |
| Programming | 3 keys (+, -, F) and LCD display |
| Operating logic | Automatic (A), Semi-automatic (E), Semi-automatic (B), Man present (C) |
| Programmable functions | Logics, Pause time A, Pause time B, Force, Opening speed, Closing speed, Opening slowing down space, Closing slowing down space, Slowing down speed, Opening direction, Opening safety logic, Closing safety logic, Pre-warning, Maximum force at start, Partial opening, Primary/Secondary, Forced commands (Hr), Sleep |
| Work time | Programmable (from 0 to 9 min and 50 sec) |
| Pause time | Programmable (from 0 to 9 min and 50 sec) |
| Thrust power | Programmable on 50 levels |
| Speed adjustment | Programmable on 10 levels |
| Terminal board inputs | BUS 2easy, 6 inputs (open A, open B, close, stop, safety opening, safety closing) |
| Terminal board outputs | 1 programmable output (failsafe, alarms, LED, courtesy light, can be activated with radio channel 2), flashing light |
| Rapid connector | XBat battery power supply, XF 433/868 module for OmniDEC and Simply Connect decoding |
| Operating ambient temperature | -20°C ÷ +55°C |
Add To Cart
Frequently Asked Questions
The FAAC E4000I is an intelligent electronic control unit designed specifically for the FAAC C4000I concealed underground sliding gate motor. The "I" designation indicates an integrated design — the control electronics are built directly into the motor unit itself, eliminating the need for a separate external control board enclosure and simplifying the overall installation significantly.
The integrated design reduces the number of components and cable runs required, resulting in a neater installation with fewer potential points of failure. For underground systems where access for future servicing needs to be planned carefully, having the control electronics within the motor housing simplifies the entire system architecture.
Despite its compact integrated design, the E4000I supports connection to essential safety and access control accessories, including photocells, safety edges, radio receivers, and intercom systems. This ensures the concealed underground system delivers the same level of safety and access flexibility as above-ground installations.
The C4000I system operates on 24V, and the E4000I control unit is compatible with battery backup solutions that maintain gate operation during mains power failures. We advise on the appropriate battery backup configuration for your installation to ensure uninterrupted access at all times.
Yes. The E4000I offers programmable travel limits, motor force sensitivity, and operational mode settings that can be configured to match the specific dimensions and usage frequency of your concealed sliding gate installation. We carry out all programming and testing during installation to ensure the system is perfectly calibrated from day one.
