V300, V400 & V500 – SWING GATE MOTOR
Sleek, stylish, secure and strong: these are some of the words that describe the V-Series linear swing gate motor for domestic and industrial gates. V-Series gate automation comes standard with battery backup offers a quick and easy (not to mention good looking) installation. It is an exceptionally strong set of operators for gates up to 4m wide, per leaf (consult specifications for further details). Boasting tough-as-nails die-cast aluminium construction throughout, a grade 304 stainless steel wormshaft for the ultimate in reliability and durability and with sophisticated electronics for smooth, safe operation, the V300, V400 and V500 give you everything you need to swing the future your way.
MAIN FEATURES:
- Exceptionally easy system setup via LCD user interface.
- Supports inward- and outward-opening gates without needing mechanical endstops.
- High push force.
- Full position control.
- Fast operating speed, with smooth acceleration and deceleration.
- Safe anti-crushing protection.
- Multiple operating features including Intruder-detection Alarm Modes (a world first).
- Onboard CENTSYS code-hopping multichannel receiver with selective add and delete.
- Battery backup for uninterrupted operation during power failures.
MODELS:
- V300 – Compact dimensions, making this operator the perfect match for smaller domestic gates
- V400 – Reliable operator with a shorter stroke for the majority of domestic swing gate applications.
- V500 – Extended stroke for larger domestic and light-industrial swing gate applications.
V-SERIES TECHNICAL DATA:
| DESCRIPTION | |
|---|---|
| Input Voltage | 90v - 240V AC +/- 10%, 50/60Hz 1 |
| Motor Voltage | 12V DC |
| Motor Power Supply | Battery-driven 21.8A Charger |
| Push Force - Max | 250kgf |
| Typical Gate Opening Time | V300 11.3 sec / V400 (short stroke) 14.3 sec / V500 (long stroke) 17.8 sec (V500) |
| Duty Cycle - Mains Present | 50% 3 |
| Daily Operations - Max | 250 |
| Maximum Leaf Width for Corresponding Gate Mass (90° opening) [****] | V300 ,2.5m = 335kg <3m = 230kg V400 ,2.5m = 500kg <4m = 150kg V500 ,2.5m = 750kg <4m = 230kg |
| Onboard Receiver Specification | CENTURION code-hopping, multichannel, 433MHz, Capacity - 65 transmitter buttons |
[*] – Can operate off a solar supply, consult CENTSYS for assistance. [**] – 7Ah battery (can be upgraded for longer power failure autonomy). [***] – Based on 25°c ambient temperature and unit not in direct sunlight. [****] – An electric lock must be fitted to gate leaves 2.5m and over to secure gate in closed position.
Add To Cart
Frequently Asked Questions
V300, V400, and V500 gate motors are designed for automating sliding gates of different weights and usage levels. They provide smooth operation, enhanced security, and reliable access control for residential and light commercial properties.
The main difference lies in gate capacity and performance. V300 suits lighter gates, V400 handles medium-duty applications, while V500 is built for heavier gates requiring stronger torque and durability.
Yes, all three models are suitable for residential use depending on gate size and weight. They ensure quiet operation, improved convenience, and secure automated access for modern homes.
Yes, routine maintenance is recommended to ensure long-term performance. Regular servicing helps prevent mechanical wear, ensures smooth operation, and extends the lifespan of V300, V400, and V500 gate motors.
Yes, these gate motors can be integrated with safety features such as obstruction detection, remote controls, and access systems, ensuring secure and user-friendly automated gate operation.
